19 Mm Pillar Drill Machines

Salient Features:

₹ 48,000

  • Drilling Capacity: 19 mm
  • Column Dia: 88 mm
  • Spindle Hole Taper: MT-3
  • Spindle Stroke 150 mm
  • Spindle Center To Pillar: 200 mm
  • Gear Hardened and Helical.
  • Motor: 1 HP
Add to Quote
Category:

Description

Technical Specifications Accessories Applications Videos
19 MM PILLAR DRILL
SPECIFICATION :-
SPINDLE CENTRE200MM
SPINDLE TRAVEL150MM
SPINDLE NOSE TO BASE DISTANCE640MM
SPINDLE NOSE TO TABLE DISTANCE400MM
TABLE TRAVEL270MM
TAPER IN SPINDLEMT-2
TABLE SIZE280MM
BASE SIZE460*320
COLUMN LENGTH1200MM
COLUMN DIAMETER74MM
RANGE OF SPEED86 TO 3300
WEIGHT OF MACHINE105KG APPROX.
MOTOR CAPACITY1 HP
V-BELT SECTIONA-44



Standard Accessories:

  • Motor pulley

Extra Accessories:

  • Tapping Control panel Board
  • Taping attachment ( Mechanical )
  • Keyless Drill chuck & arbor
  • v belt
  • Drill chuck & Arbor
  • Coolant pump with coolant tank
  • Electric Motor

Our Heavy Duty Drilling Machines is used Majorly in All Tool Room Machines as it has High Center Capacity and 10" Stroke it stands out From many other manufacturers.

  • Automobile
  • Tool Room & General Maintenance
  • Pump and valve industry
  • Repairing workshops
  • Engineering colleges and ITI's
