Imported Vertical Milling Machines

Salient Features:

₹ 3,55,000 – 7,80,000

  • Hardened & Precision Ground On X Y Ways And Table.
  • 3 Power Quill Feed With Automatic Stop.
  • Grinding On Slideways Of Column.
  • Chrome Plated & Precision Ground On Quill.
  • Centralised One Shot Lubrication System For All Slideways, Nuts And Leadscrew.
  • Hardened & Ground On Spindle Gear Back Gear And Gear Clutch.
  • Pre Loaded Double Nuts Ensure Extremely Smooth, High Precision Working & Minimize Backlesh.
  • C E Certified Elecrical System.
  • Turcite B, On X Y Ways For Maximum Wear Resistant. With Hand Scap.
Add to Quote
Category:

Description

Technical Specifications Accessories Applications Videos
SPECIFICATION UNITS 4S4S - 14RS 4S- SPECIAL 5S
TABLE SIZEMM1270 X 2541270 X 2541270 X 2541320 X 2541370 X 280
T-SLOT OF TABLE [QTY. X SIZE] MM3 X 16
LONGITUDINAL TRAVEL [X-AXIS]MM900900900950950
CROSS TRAVEL [Y-AXIS] MM375375375410450
RAM TRAVELMM500
QUILL TRAVELMM127
QUILL FEED RATEMM0.04-0.08-0.14
SPINDLE TO TABLE NOSE [DISC.]MM500500500500520
SPINDLE TAPER R8/ ISO-30 / ISO-40
NO. OF SPEED 16 STEP
SPINDLE RANGE [RPM]16 STEP66 - 4540 [50Hz]
MOTOR POWERHP 3
OVER SWIVEL OF TURRETDEG360
HEAD SWIVEL [R&L]DEG45
HEAD SWIVEL [UP & DOWN]DEG45
HEAD TYPES OPTIONS SQUARE/ROUNDSQUARE/ROUNDSQUARE SQUARE/ROUNDSQUARE/ROUND
SIDEWAYS X - AXIS DOVETAIL DOVETAIL DOVETAIL DOVETAIL DOVETAIL
Y - AXIS DOVETAIL SQUAREDOVETAIL SQUARESQUARE
Z - AXIS DOVETAIL DOVETAIL DOVETAIL DOVETAIL DOVETAIL
OVERALL HEIGHTMM21202120212021202120
OVERALL DEPTHMM19841984198419841984
OVERALL WIDTHMM16661666166616661666
NET WEIGHT (APPROX) KG KGS10801100108011001250
STANDARD ACCRSSORIES DRO SET / DRAW BAR / RUBBER CHIP COVER / ONE SHOT LUBRICATION PUMP
WORKING LAMP / ELECTRICAL PANEL / TOOL BOX / OPERATION MANUAL

OPTIONAL ACCESSORIES VICE / CLAMPING KIT / BORING HEAD WITH SHANK / COLLET SET / EDGE FINDER
KEYLESS DRILL CHUCK WITH ARBOR / SLEEVE MT-1 / MT-2 / MT-3
